White NW8 Non-Woven Geotextile Cuts 100gsm

White NW8 Non-Woven Geotextile Cuts 100gsm

by Spudulica
£14.05 - £32.99
£23.00
£14.05 - £32.99
£23.00
SKU 1.1x10SOAK

Non-Woven geotextile membrane cuts

Commercial grade 100GSM non-woven geotextile membrane, perfect for filtration and separation applications, such as;

  • french drains, trench lining
  • soakaway and attenuation tank wrapping

All products are thermally bonded to provide a tough fabric that has been proven to be one of the highest quality general purpose membranes on the market today!

 Mechanical Properties Test Unit Multitrack NW8
Tensile Strength - MD EN ISO 10319 kN/m 8.0
Tensile Strength - XD EN ISO 10319 kN/m 8.0
Elongation At Break - MD EN ISO 10319 % 40
Elongation At Break - XD EN ISO 10319 % 45
CBR Puncture Resistance EN ISO 12236 N 1400
Dynamic Cone Drop EN 912 mm 34.0
Protection Efficiency WI 189066 N 65.0
Hydraulic Properties
Permeability EN ISO 11058 m/s 110 x 10-3
Waterflow Normal To The Plane EN ISO 11058 l/m2.s 110
Waterflow In The Plane EN ISO 12958 m2/s 1 x 10-7
Characteristic Opening Size EN ISO 12956 µm 130.0
Physical Properties
Thickness Under 2kPa EN 964/1 mm 1.00
Weight EN 965 g/m2 110.0
Roll Width m 4.50
Roll Length m 100
Roll Diameter (+/-10% cm 42
